Marc Mundt · May 13

Many systems that send HL7 over HTTP use very simple requests -- they just send the raw HTML as the HTTP request body. There's no SOAP layer on top. This is the approach that EnsLib.HL7.Operation.HTTPOperation uses.

HTTP docs say that 415 could indicate that the content-type header is specifying a content type that the receiving system doesn't like. Assuming the recipient doesn't actually need SOAP, if you can find out what content type they are looking for, you can change this in the Business Operation settings under Additional Settings/ContentType.

If the receiving system really does need a SOAP call you can look at EnsLib.HL7.Operation.SOAPOperation. I haven't seen this in use so I don't know the details but it might be worth a try.

Marc Mundt · Apr 28

Here's how you can iterate through the results:

 set query = "SELECT Facility FROM FROM osuwmc_EnterpriseDirDB.RelationshipMedCtrID WHERE OSUmedcenterID = ?"
 SET rset = ##class(%SQL.Statement).%New()
 SET qStatus = rset.%Prepare(query)
 SET rset = rset.%Execute($Get(ID))

 while (rset.%Next()) {
    // Check Facility value in each row
    set facility=rset.%Get("Facility")
    if (facility = "SOMEVALUE") {
        //...
    }
 }
Marc Mundt · Feb 27

As Enrico mentioned, the rule logic is stored as XML in a rule class, so you can't query the logic directly via SQL.

You can find the names of all rule classes using SQL:
SELECT ID FROM %Dictionary.ClassDefinition where Super='Ens.Rule.Definition'

To then view the rule logic you would need to open a class and view the "RuleDefinition" XData block:

Class ORU.RouterRoutingRule Extends Ens.Rule.Definition
{

Parameter RuleAssistClass = "EnsLib.HL7.MsgRouter.RuleAssist";

XData RuleDefinition [ XMLNamespace = "http://www.intersystems.com/rule" ]
{
<ruleDefinition alias="" context="EnsLib.HL7.MsgRouter.RoutingEngine" production="ADTPKG.FoundationProduction">
<ruleSet name="" effectiveBegin="" effectiveEnd="">
<rule name="">
<when condition="1" comment="">
<send transform="Demo.ORUTransformation" target="ORU.Out"></send>
<send transform="Demo.ORUTransformation" target="ORU.Two"></send>
</when>
</rule>
</ruleSet>
</ruleDefinition>
}

}
Marc Mundt · Jan 31

No errors are appearing in the OUTPUT tab.

The package contains only custom classes.

Not sure if this is the right config -- let me know if not. I'm on Linux and this is ".config/Code/Workspaces/1731519734832/workspace.json" The problematic item is irishealth:CVSCCDA.

{
        "folders": [
                {
                        "name": "irishealth:AUTOMATION",
                        "uri": "isfs://irishealth:automation/"
                },
                {
                        "name": "irishealth:FHIRCONVERSION",
                        "uri": "isfs://irishealth:fhirconversion/"
                },
                {
                        "name": "irishealth:%SYS",
                        "uri": "isfs://irishealth:%sys/"
                },
                {
                        "name": "irishealth:CVSCCDA",
                        "uri": "isfs://irishealth:cvsccda/"
                }
        ]
}

Marc Mundt · Dec 5, 2024

I haven't tested this, but this is what I'm suggesting. New part is colored blue.

XData BPL [ XMLNamespace = "http://www.intersystems.com/bpl" ]
{
<process language='objectscript' request='CUH.Mess.DCIQ.JsonIn' response='CUH.Mess.DCIQ.JsonOut' height='3400' width='2000' >
<context>
<property name='JsonObjectIn' type='CUH.Mess.DCIQ.JsonInObj' instantiate='1' />
<property name='HL7QRY' type='EnsLib.HL7.Message' instantiate='0' />
<property name='HL7ADR' type='EnsLib.HL7.Message' instantiate='0' />
<property name='JsonObjectOut' type='CUH.Mess.DCIQ.JsonOutObj' instantiate='1' />
<property name='RequestNumber' type='%String' initialexpression='""' instantiate='0' >
<parameters>
<parameter name='MAXLEN'  value='50' />
</parameters>
</property>
<property name='IsInteger' type='%Boolean' instantiate='0' />
<property name='ProcError' type='%String' initialexpression='""' instantiate='0' >
<annotation><![CDATA[Error message to be sent back in the Response.]]></annotation>
<parameters>
<parameter name='MAXLEN'  value='50' />
</parameters>
</property>
<property name='ValidOriginUrl' type='%String' instantiate='0' >
<parameters>
<parameter name='MAXLEN'  value='100' />
</parameters>
</property>
<property name='ValidContactType' type='%String' instantiate='0' >
<parameters>
<parameter name='MAXLEN'  value='50' />
</parameters>
</property>
<property name='ValidIDNumberType' type='%String' initialexpression='""' instantiate='0' >
<parameters>
<parameter name='MAXLEN'  value='50' />
</parameters>
</property>
<property name='ValidNHSCodeType' type='%String' initialexpression='""' instantiate='0' >
<parameters>
<parameter name='MAXLEN'  value='50' />
</parameters>
</property>
</context>
<sequence xend='200' yend='3500' >
<scope xpos='200' ypos='250' xend='200' yend='2850' >
<annotation><![CDATA[Handles all errors]]></annotation>
<code name='Initialize JSON request' xpos='200' ypos='350' >
<![CDATA[ set context.JsonObjectIn = ##class(CUH.Mess.DCIQ.JsonInObj).%New()
 do context.JsonObjectIn.%JSONImport(request.bodyJson)]]>
</code>
<if name='Is "data" an array?' condition='context.JsonObjectIn.data.%IsA("%DynamicArray")' xpos='200' ypos='450' xend='200' yend='700' >
<true>
<assign name="Make &quot;data&quot; a %DynamicObject" property="context.JsonObjectIn.data" value="context.JsonObjectIn.data.%Pop()" action="set" xpos='335' ypos='600' />
</true>
</if>
<assign name="Valid URL" property="context.ValidOriginUrl" value="##class(Ens.Util.FunctionSet).Lookup(&quot;CUH.DCIQToEpic.OriginUrl&quot;,$NAMESPACE,&quot;&quot;,3)" action="set" languageOverride="" xpos='200' ypos='800' >
<annotation><![CDATA[Environment specific]]></annotation>
</assign>
<assign name="Valid ContactType" property="context.ValidContactType" value="##class(Ens.Util.FunctionSet).Lookup(&quot;CUH.DCIQToEpic.ContactType&quot;,$NAMESPACE,&quot;&quot;,3)" action="set" languageOverride="" xpos='200' ypos='900' >
<annotation><![CDATA[Environment specific]]></annotation>
</assign>
<assign name="Valid IDNumberType" property="context.ValidIDNumberType" value="##class(Ens.Util.FunctionSet).Lookup(&quot;CUH.DCIQToEpic.IDNumberType&quot;,$NAMESPACE,&quot;&quot;,3)" action="set" languageOverride="" xpos='200' ypos='1000' >
<annotation><![CDATA[Environment specific]]></annotation>
</assign>
<assign name="Valid NHSCodeType" property="context.ValidNHSCodeType" value="##class(Ens.Util.FunctionSet).Lookup(&quot;CUH.DCIQToEpic.NHSCodeType&quot;,$NAMESPACE,&quot;&quot;,3)" action="set" languageOverride="" xpos='200' ypos='1100' >
<annotation><![CDATA[Environment specific]]></annotation>
</assign>
<if name='Check OriginUrl' condition='context.JsonObjectIn.meta."origin_url"=context.ValidOriginUrl' xpos='200' ypos='1200' xend='200' yend='2600' >
<true>
<if name='Check Contact Type' condition='(context.JsonObjectIn.data."0"."con_type"=context.ValidContactType)||(context.JsonObjectIn.data."con_type"=context.ValidContactType)' xpos='470' ypos='1350' xend='470' yend='2500' >
<true>
<if name='Check idNumber Type' condition='(context.JsonObjectIn.data.idNumbers.GetAt(1).type)=context.ValidIDNumberType' xpos='740' ypos='1500' xend='740' yend='2400' >
<true>
<assign name="Get Request Number" property="context.RequestNumber" value="context.JsonObjectIn.data.idNumbers.GetAt(1).number" action="set" languageOverride="" xpos='1010' ypos='1650' />
<code name='Integer pattern' xpos='1010' ypos='1750' >
<![CDATA[ set context.IsInteger = ((context.RequestNumber)?.N)]]>
</code>
<if name='Integer?' condition='context.IsInteger' xpos='1010' ypos='1850' xend='1010' yend='2300' >
<annotation><![CDATA[Checks if Requested Number sent is an Integer]]></annotation>
<true>
<transform name='Create HL7 query' class='CUH.Tran.GetDCIQJsonPatientToEpicQRYQ011' source='context.JsonObjectIn' target='context.HL7QRY' xpos='1280' ypos='2000' />
<call name='Send to MPIQueryHandler' target='MPI Query Handler' async='0' xpos='1280' ypos='2100' >
<request type='EnsLib.HL7.Message' >
<assign property="callrequest" value="context.HL7QRY" action="set" languageOverride="" />
</request>
<response type='EnsLib.HL7.Message' >
<assign property="context.HL7ADR" value="callresponse" action="set" languageOverride="" />
</response>
</call>
<transform name='Converts HL7 to JSON' class='CUH.Tran.EpicADRA19ToDCIQJsonPatient' source='context.HL7ADR' target='context.JsonObjectOut' xpos='1280' ypos='2200' />
</true>
<false>
<assign name="Error No Number" property="context.ProcError" value="&quot;MRN needs to be a positive numeric value&quot;" action="set" languageOverride="" xpos='1010' ypos='2000' />
</false>
</if>
</true>
<false>
<assign name="Error idNumber Type" property="context.ProcError" value="&quot;Invalid idNumber Type&quot;" action="set" languageOverride="" xpos='740' ypos='1650' />
</false>
</if>
</true>
<false>
<assign name="Error Contact Type" property="context.ProcError" value="&quot;Invalid Patient Contact Type&quot;" action="set" languageOverride="" xpos='470' ypos='1500' />
</false>
</if>
</true>
<false>
<assign name="Error Origin Url" property="context.ProcError" value="&quot;Origin URL not authorized!&quot;" action="set" languageOverride="" xpos='200' ypos='1350' />
</false>
</if>
<faulthandlers>
<catchall xpos='200' ypos='2700' xend='200' yend='350' >
<assign property="context.ProcError" value="&quot;Error in the Json/HL7 conversion/transformation block&quot;" action="set" languageOverride="" xpos='200' ypos='250' />
</catchall>
</faulthandlers>
</scope>
<assign name="Assign Error to Response" property="context.JsonObjectOut.errors" value="context.ProcError" action="set" languageOverride="" xpos='200' ypos='2950' />
<if condition='context.JsonObjectOut.errors&apos;=""' xpos='200' ypos='3050' xend='200' yend='3400' >
<annotation><![CDATA[Check if any errors]]></annotation>
<true>
<trace name='Log the Error' value='context.JsonObjectOut.errors' xpos='470' ypos='3200' />
<assign name="Returns {}" property="response.bodyJson" value="&quot;{}&quot;" action="set" languageOverride="" xpos='470' ypos='3300' />
</true>
<false>
<code name='Returns Valid Response' xpos='200' ypos='3200' >
<![CDATA[ set temp = ##class(CUH.Mess.DCIQ.JsonOut).%New()
 do context.JsonObjectOut.%JSONExportToString(.temp)
 set response.bodyJson = temp]]>
</code>
</false>
</if>
</sequence>
</process>
}
Marc Mundt · Dec 5, 2024

One thing you could do:
At the top of your BPL, add an <if> checking if "data" is an array or an object:

if context.JsonObjectIn.data.%IsA("%DynamicArray")

If it is, then use an assign to set context.JsonObjectIn.data to the last element of the array (%Pop() returns the last element of an array):

set context.JsonObjectIn.data = context.JsonObjectIn.data.%Pop()

After doing this, the rest of the actions should work the same for either input.

Note that this assumes that when "data" is an array that the array only has one item in it. If it can have multiple items then you'll need to add logic to choose the correct item.
